Adjustable Latch Toggle Clamp 431 Oil Resistance Rubber Handle Weight 210g

Brand Name : dls

Model Number : 431

Certification : ISO9001:2008

Place of Origin : Dongguan China

MOQ : 10 pcs

Payment Terms : L/C, T/T, Western Union

Supply Ability : 3000 pcs per week

Delivery Time : 7 days

Packaging Details : poly bag and carton box

WEIGHT : 210G

Holding force : 318kgs

Material : Cold Roll Sheet

Mounting Hole Dia. : 6.7mm

Screw : Lock nut

Warranty : 1 year

Contact Now

Latch Type Toggle Clamp 431 Oil Resistant Rubber Handle Holding Force 318kgs Weight 210g Most Popular Clamp

Product Specification and features:

Holding force : 318kgs

weight:210g

1.Ideal for use on doors, machinery, automobiles, jig assemblies and other medium to heavy-duty job applications.
2.Material: Cold-rolled carbon Steel with Zinc plated coating for corrosion resistance.
3.Easy Operate:Streamlined latch-mechanism features strength and adjustability. Plastic cover handle for easy, safe and comfortable operation, with adjustable u bolt.
4.Holding Capacity: 701 lbs /318kg. Clamp base:1.65*1.73inches, mounting holes: about 0.28”; Clamp height when clamped:1.75”. Total length range, including handle, when clamped: 6.85".

Adjustable Latch Toggle Clamp 431 Oil Resistance Rubber Handle Weight 210g
