Pneumatic Swing Pull Clamps Alluminium Alloy Rotary Clamp Cylinder

Name: Pneumatic Swing Pull Clamps Alluminium Alloy Rotary Clamp Cylinder
Brand: Jiayan
Price: 1 USD

Quality Pneumatic Swing Pull Clamps Alluminium Alloy Rotary Clamp Cylinder wholesale

Brand Name : Jiayan

Model Number : 035-225-290

Certification : ISO9001

Place of Origin : Dongguan China

MOQ : 1 pc

Price : Negotiable

Payment Terms : L/C, T/T, Western Union,Paypal

Supply Ability : 500 pcs per week

Delivery Time : 7 days

Packaging Details : inner plastic and outer carton box

Stroke (mm) : 26.7

Cylinder Bore (mm) : 25

Clamping Force @ 5Bar[72Psi : 1

Mount : Flanged Body

Swing Direction : LH

Air Port size : 10-32

Air Consumption (per double stroke at 5 bar) (dm³) : 0.130

Stroke during rotation (mm) : 13.7

Vertical clamp stroke (mm) : 13.0

Sensor Ready : No

Weight (kg) : 0.25

Product Series Description : Swing Clamp

Contact Now

Pneumatic Swing Pull Clamps Alluminium Alloy Rotary Clamp Cylinder

Swing Clamp Features:

Swing motion available in 0, 45, 60, and 90 degrees
Two styles of arms
Double-locked arm design is bolted to piston shaft and around shaft diameter for extra rigidity
Flanged body

Quick swing-and-clamp movement
Uniquely adaptable for welding and assembly operations

Clamping force in direct proportion to bore size and inlet pressure non-locking

Swing Clamp Specification:

Stroke (mm) :26.7
Stroke (in) :1.050
Cylinder Bore (mm) :25
Cylinder Bore (in) 0.98
Clamping Force @ 5Bar[72Psi] (N): 20
Clamping Force @ 5Bar[72Psi] (lbf.) :50
Mount :Flanged Body
Swing Direction :LH
Air Port size :10-32
Air Consumption (per double stroke at 5 bar) (dm³) :0.130
Air Consumption (per double stroke at 7 psi) (in³): 0.005
Stroke during rotation (mm) :13.7
Stroke during rotation (in) :0.54
Vertical clamp stroke (mm) :13.0
Vertical clamp stroke (in): 0.51
Sensor Ready: No
Weight (kg) :0.25
Weight (lb) :0.56
Product Series Description :Swing Clamp
