Double acting clamp Left Right rotation pneumatic cylinder 50mm bore rotating swing clamp cylinder 90 degree

Name: Double acting clamp Left Right rotation pneumatic cylinder 50mm bore rotating swing clamp cylinder 90 degree
Brand: Jiayan
Price: 1 USD

Quality Double acting clamp Left Right rotation pneumatic cylinder 50mm bore rotating swing clamp cylinder 90 degree wholesale

Brand Name : Jiayan

Model Number : HSR

Certification : ISO9001

Place of Origin : Dongguan China

MOQ : 1 pc

Price : Negotiable

Payment Terms : L/C, T/T, Western Union,Paypal

Supply Ability : 500pcs per week

Delivery Time : 7 days

Packaging Details : inner plastic and outer carton box

Body Material : Aluminum

Structure : Rotary Cylinder

Power : Pneumatic

Certificate : ISO9001, CE, RoHS

Fluid : Air(no lubrication)

Working Type : Double acting

Working Pressure : 0.15~0.95MPa

Working temperature : 0~80 degree

Working speed(mm/sec) : 30~500

Rotating stroke : 15

Rotate angel : 90 degree

Contact Now

Double acting clamp Left Right rotation pneumatic cylinder 50mm bore rotating swing clamp cylinder 90 degree

Features:

1:SRC Pneumatic Cylinder-SMC Type Pneumatic Clamping Cylinder
2:Bore size: 25-63mm
3:right and left direction for select.

SRC Pneumatic Cylinder-SMC Type Pneumatic Clamping Cylinder

1).Bore:25mm, 32mm, 40mm, 50mm, 63mm
2).Small size and light weight.
3).Long service of life, easy to control and maintain.
4).Interchange with SMC

Bore size(mm)	25	32	40	50	63
Fluid	Air(no lubrication)
Working Type	Double acting
Working temperature	0.15~0.95MPa
Working temperature	0~60 degree
Working speed(mm/sec)	30~500
Rotate stroke	11	13		15
Rotate angel	90 degree(can customize 0/45/60 degree
Rotate direction	left(anticlockwise),right(clockwise)
Port size	M5x0.8
